Still waiting for a driver that will allow me to post legal scores here lol. In fact in windows 7 the ONLY one that works at all is 185.2. Anyway vantage score almost to 21k now on the Graphics test : )
http://service.futuremark.com/compare?3dmv=812870
OS-Wiz
I see your score and raise you 1 i7 :D Couldn't resist 920 for $229 and $119 for 6GB.
Nice score! PhysX on or off? What mobo and HSF you using with the new i7 920, if its an ASUS P6T Deluxe I've some settings you might find useful.Quote:
Originally Posted by ewitte
I'm 121st on Step-up plan for a 295 with eVGA :D
Did you notice lower GPU temps using the back-plate?
EDIT: are you using the eVGA Voltage Tuner?
Usually have PhysX onQuote:
Originally Posted by OS-Wiz
p6t deluxe
backplate not installed yet. was about to do it with the i7 install but couldn't find the small screwdriver.
eVGA volate tuner 100% fan will not go over 1188mv
Nice side by side q9550 versus i7. The 9550 results are 100% tweaked but not anywhere near i7 max results ;) My i7 will do 4Ghz with only 1.225v! BTW with much lower GPU settings as well and HT off (until I can control the heat better).
20418 http://service.futuremark.com/compare?3dm06=10188559
24657 http://service.futuremark.com/compare?3dm06=10223117
Vista with WHQL drivers that should eventually get approved. BTW what I like is all the minimum FPS readings are like 50% higher!
Usually have PhysX on PhysX must be off for legit post to ORB once we get some FM approved WHQL drivers.
http://www.sharkyforums.com/images/i...2009/11/19.jpg
http://www.sharkyforums.com/images/i...2009/11/20.jpg
**** WARNING WARNING you MUST have excellent cpu cooling ****
The following BIOS settings got me to 4.2Ghz, see recommendation below on how I got there.
C1E: disable
Hardware Prefetcher: disable
Adjacenct Cache: disable
Intel VT: disable
CPU TM: disable
Exceute Disable Bit: disable
Intel HT: Enable
Active Processore Cores: Enable
A20M : disable
Intel Speed Step: Enable ( *Turbo On Multiple @ 21)
Intel Turbo Mode: Enable ( *Turbo On Multiple @ 21)
Intel C-STATE: disable
Set your memory timings to those recommended by maker and Vdimm to 1.65
CPU Ratio Setting: Auto
BCLK: 200Mhz
PCIE: 100Mhz
DRAM: 1600Mhz (I'm using DDR3 1600 ram, your's may be different)
Vcore: 1.45V
CPU Pll: auto
QPI/DRAM: auto
IOH: auto
IOH PCIE: auto
ICH: auto
ICH PCIE: auto
DRAM Bus: 1.64V
Load-Line Calibration: Enable
CPU Clock Skew: auto
CPU Spread Spectum: Disable
IOH Clock Skew: auto
PCIE Spread Spectum: Disable
Bump up Vcore one notch from stock (1.08) and set Bclk to 140. Boot and make sure you're stable (Prime95??? or your app of choice). Keep cpu temp at or below 74c. Then slowly move up to 4.2Ghz by bumping Bclk 10Mhz at a time up to 180, then by 5Mhz to 200, booting after each bump and checking stability. For each bump in Bclk bump Vcore two notches up to 1.45. Check DRAM Freq at each bump in Bclk to be sure you are at or below max freq for your memory.
I haven't even attempted a legit score as beta drivers will never get certified ;) I do have Vista installed now so maybe a run there. BTW temps are a PITA even at 1.085v and HT off its 79C right now at 13 hours prime. My 1.085v settings are 3.6Ghz. Doing serious work on the air flow to keep the 295 air off the CPU over the weekend. That alone added 10C to my q9550. I can however get some decent single threaded overclocks ;)
http://s150233688.onlinehome.us/spi43.jpg
You need a TRUE and a couple 120mm fans :eek:Quote:
Originally Posted by ewitte
Two Antec fans: http://www.newegg.com/Product/Produc...82E16835209006 selectable speeds, quiet when not OCing, 79CFM when OCing.
https://www.sharkyforums.com/images/...2009/03/17.jpg
Just pointing the top 120mm down and adding another at the top dropped me 10C. I'll probably be able to get another 10C. I doubt I will spend much to upgrade the air cooling because I'm looking at H2O again ;)
man i just killed alot of scores
i <3 CF
So where's the score?! I'd love to see more red team members in top ten!:DQuote:
Originally Posted by stang10001
its mid 18k lets say that. just dont have enough time to arrange the post atm
Benchmark: 3Dmark06
CPU: AMD Phenom II X3 720
Stock Speed of CPU: 2.8
Overclocked speed of CPU: 3.4
MotherBoard: Asus M4A78T-E
Ram: 1 GB
Video Card: 2 visiontek 4850's
Stock Core of Video: 625 MHz
Actual Core of Video: 750 MHz
Stock Mem of Video: 1986 MHz
Actual Mem of Video: 2450 MHz
Cooling Used: video = stock, CPU = stock atm
Your scores with links: 18950 http://service.futuremark.com/compare?3dm06=10767968
aww out of 3rd by 3 points
maybe the video cards need more voltage
Done! 'Grats on making top 5!!!:eek: BTW, I do need a little more info about the RAM....I ain't psychic ya know.:p:DQuote:
Originally Posted by stang10001
1 gb DDR3 8500 6-7-7-24Quote:
Originally Posted by mikeysg
i don't remember brand. its the cheap stuff. so its prolly crucial
Okey-dokey, edited your spec to reflect the RAM....nice job!:D You might be able to take me down a notch at '05.....go fer it!;)
don't feel like installing 05 yet lol
hey mikey im about to throw down a monster 06 score for my setup.
Benchmark: 3Dmark06
CPU: AMD Phenom II X3 720
Stock Speed of CPU: 2.8
Overclocked speed of CPU: 3.8
MotherBoard: Asus M4A79T
Ram: 2 GB 11-11-11-33 (DONT ASK)
Video Card: 2 visiontek 4850's
Stock Core of Video: 625 MHz
Actual Core of Video: 704 MHz
Stock Mem of Video: 1986 MHz
Actual Mem of Video: 2202 MHz
Cooling Used: video = water, CPU = water
Your scores with links:19794 http://service.futuremark.com/compare?3dm06=11201434
i wish i would have gotten a 955 instead of a 720
Done!;) But I gotta know exactly what RAM and cooling you're using.....'water' just doesn't cut it, know what I mean?:p:DQuote:
Originally Posted by stang10001
Edit - BTW, most excellent score there dude! :)
crucial 1800
cpu gtz gpu mcw-60
OK, it's updated.....;)Quote:
Originally Posted by stang10001
im surprised dr13zehn isnt coming to redeem himself. hes in 5th still
http://service.futuremark.com/compare?3dm06=10444885
20,608
gpu gtx285 mhz - 675
memory - 2520
shader - 1548
cpu q9650 9x452 = 4050 mhz
mushkin 4gb 1066
asus p5q pro
sorry stang but I ain't given up 3rd without a fight
I am going to take a run with the above processor and xfired 4850s
like i said i need the damn 955
im using 9.5 for drivers and they limit me to 704/1101 instead of 750/1165. and that extra bandwidth helps alot.
Hi all, haven't been doin' much benching in awhile. Good to see a few OCer are still hangin out here. Anybody know the core placement numbers when the i7 chip is in the socket? My guess is:
3 1
4 2?
At idle core 1 & 2 are at 43c and 3 & 4 are at 39c. I'm thinking my HS isn't mounted right or the heat spreader isn't square with the cores or something. And yes, I've remounted the HS several times and each time the TIM seems evenly spread across the heat spreader. So I'm stumped, any ideas? Perhaps I need to lap the heat spreader?
